Allen & Heath XONE:96 Professional 6-Channel Analog DJ Mixer

Product image 1
Product image 2
Product image 3
Product image 4
Product image 5

Allen & Heath XONE:96 Professional 6-Channel Analog DJ Mixer

Allen & Heath XONE:96 Professional 6-Channel Analog DJ Mixer

Key Features
  • Six-Channel Mixer
  • Dual USB Sound Card
  • Dual VCFs (LP, BP, HP)
  • Crunch Circuit: Harmonic Distortion
  • 3-Band Parametric EQ on Inputs A & B
  • 4-Band EQ on Channels 1-4
  • 2 x Stereo FX Sends + 4 x Stereo Returns
  • Replaceable VCA Channel Faders
  • Cross-Fader: innoFADER
  • Headphone Outputs: 2 x 1/4" & 1/8"

Overview

Building upon the success of the XONE:92, the Allen & Heath XONE:96 is a flexible, professional six-channel DJ mixer designed for nightclub and venue installation. The XONE:96 is updated with a dual 32-bit/96kHz soundcard with two USB connections for up to 24 channels of I/O. There are two independent headphone amplifier circuits with 1/4" and 1/8" connections that, when combined with the two separate soundcards, allow for some serious back-to-back sessions and seamless DJ transitions. The classic dual VFC filters (LP, BP, HP) offer frequency cutoff and resonance controls and have been updated with a "Crunch" circuit, which offers controlled harmonic distortion (pre-filter).

Channels 1-4 offer four turntable (phono) and four line inputs on RCA connections, while channels A and B feature balanced XLR microphone inputs and stereo 1/4" line inputs. The XONE:96 is packed with sonic and performance enhancing features that include a powerful four-band EQ on channels 1-4 and a 3-band parametric EQ on channels A & B. Additional features include user replaceable 60mm VCA channel faders, and a replaceable innoFADER Mini crossfader.

Two mix outputs feature balanced XLR and unbalanced RCA connections, while the booth output features stereo 1/4" connections. A stereo pair of RCA outs is available for recording the mixer's outputs. Two stereo auxiliary sends and four stereo returns route signal to external effects and signal processors. The Allen & Heath XONE:96 is a professional DJ mixer and designed to surpass the expectations of the most demanding professional DJs.

Key Specs

Configuration
DJ Mixer
Number of Channels
6x Stereo
2x Mic
Performance Controls
Band-Pass Filter, High-Pass Filter, Low-Pass Filter
Built-In Effects
Distortion
Audio Inputs
4x Stereo 2RCA Coaxial DVS Return/Phono Input
4x Stereo 2RCA Coaxial Line Input
2x XLR 3-Pin Mic Input
4x 1/4" TRS Line Input
1x 1/4" TRS Hi-Z/Return Input
3x 1/4" TRS Return Input
2x 1/4" TRS Return Input
Audio Outputs
2x XLR 3-Pin Balanced Master Output
2x 1/4" TRS Balanced Master Output
2x 1/4" TRS Balanced Booth Output
1x Stereo 2RCA Coaxial Unbalanced Record Output
1x 1/4" TRS Send Output
3x 1/4" TRS Send Output
2x 1/4" TRS Headphone Output
2x 1/8" / 3.5 mm TRS Headphone Output
USB
2x USB-B 2.0 (Class Compliant/Audio I/O)
Number of Channels
6x Stereo
2x Mic
Platter/Jog Wheel
No
Faders
6x 2.4" / 60 mm Channel Level (Replaceable, Adjustable Fade Curve)
1x 1.8" / 45 mm Crossfader (Replaceable, Adjustable Fade Curve)
Meters
Channel Meter:
4x 9-Segment LED
Main Meter:
2x 9-Segment LED
Meter Range
No
Display
No
Sample Pads
No
EQ
2x Mic/Aux EQ:
Hi
Mid (Semi-Parametric)
Low
4x Channel EQ:
Hi
Hi-Mid
Lo-Mid
Low
Performance Controls
Band-Pass Filter, High-Pass Filter, Low-Pass Filter
Built-In Effects
Distortion
Sample Rates
96 kHz
Bit Depths
32-Bit
Stems Processing
No
Connectivity
Audio Inputs
4x Stereo 2RCA Coaxial DVS Return/Phono Input
4x Stereo 2RCA Coaxial Line Input
2x XLR 3-Pin Mic Input
4x 1/4" TRS Line Input
1x 1/4" TRS Hi-Z/Return Input
3x 1/4" TRS Return Input
2x 1/4" TRS Return Input
Audio Outputs
2x XLR 3-Pin Balanced Master Output
2x 1/4" TRS Balanced Master Output
2x 1/4" TRS Balanced Booth Output
1x Stereo 2RCA Coaxial Unbalanced Record Output
1x 1/4" TRS Send Output
3x 1/4" TRS Send Output
2x 1/4" TRS Headphone Output
2x 1/8" / 3.5 mm TRS Headphone Output
Other I/O
1x DIN 5-Pin MIDI Output
1x RJ45 Link Output
2x Phono Ground Terminal
Phantom Power
No
USB
2x USB-B 2.0 (Class Compliant/Audio I/O)
Wireless
No
Media Card Slots
No
Performance
Headroom
20 dB
Crosstalk
<-83 dB
THD
<0.05%
Compatibility
Included Software
No
Compatible Software (Not Included)
Traktor Pro Traktor Scratch pro 2
OS Compatibility
macOS / Windows
OS Compatibility
macOS
Windows
Mobile App Compatible
No
Required Hardware
USB 2.0 Port
Internet Connection
Required for Registration, Software/Driver Download
Power
Power Requirements
AC/DC Power Adapter (Included)
AC Input Power
100 to 240 VAC, 50/60 Hz
AC Power I/O
1x IEC
Power Consumption
45 W (Maximum)
Physical
Anti-Theft Features
Kensington Security Slot
Dimensions (W x D x H)
13.3 x 16.2 x 4.3" / 336.0 x 410.0 x 109.0 mm
Weight
15.4 lb / 7 kg
Packaging Info
Package Weight
19.05 lb
Box Dimensions (LxWxH)
21 x 18.5 x 8"



What's in the Box

  • Allen & Heath XONE:96 Professional 6-Channel Analog DJ Mixer
  • Power Cord
  • Limited 1-Year Manufacturer Warranty
