Blackmagic Design Micro Studio Camera 4K G2

Product image 1
Product image 2
Product image 3
Product image 4

Blackmagic Design Micro Studio Camera 4K G2

Blackmagic Design Micro Studio Camera 4K G2

Key Features
  • Active Micro Four Thirds Lens Mount
  • UHD 4K Resolutions up to 3840 x 2160p60
  • 12G-SDI Video Input/Output, HDMI Output
  • 13-Stop Dynamic Range, Compact Design
  • Camera Control via SDI, HDMI, or USB
  • Program and Talkback over SDI, Tally
  • USB-C Expansion Port, 3.5mm Audio In
  • Built-In Color Corrector
  • Canon LP-E6 Battery Slot

Ā

Overview

Install a camera anywhere in your studio or on location with the ultracompactĀ Blackmagic Design Micro Studio Camera 4K G2. This tiny UHD 4K studio camera is designed for live productions and has been updated to feature the same image sensor found in Blackmagic's Studio Camera 4K Plus G2, which supports 3840 x 2160p60. The camera is equipped with an active MFT mount that can accept native MFT lenses or be adapted to a wide range of other modern and vintage lenses. It outputs 10-bit 4:2:2 video via 12G-SDI and can be remotely controlled from an ATEM switcher using SDI control protocol. The camera packs many professional studio features into a compact form factor, including a built-in color corrector, program return, talkback, and tally indicator.

Key Specs

Image Sensor
17.78 x 10 mm (Four Thirds) CMOS
Sensor Resolution
Not Specified by Manufacturer
Lens Mount
Micro Four Thirds
Broadcast System Compatibility
NTSC, PAL
Video I/O
1x HDMI 2.0 Output
1x Micro BNC (12G-SDI) Input
1x Micro BNC (12G-SDI) Output
Audio I/O
1x 1/8" / 3.5 mm TRS Stereo Microphone Input
Recording Modes
DNxHD/ProRes:
3840 x 2160p at 23.98/24/25/29.97/30/50/59.94/60 fpsĀ
1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fpsĀ
Raw Recording
Blackmagic RAW
3840 x 2160 at 23.98/24.00/25/29.97/50/59.94/60 fps [26 to 190 Mb/s]
Display Type
No
Power I/O
1x Barrel (12VDC) Input
Imaging
Image Sensor
17.78 x 10 mm (Four Thirds) CMOS
Sensor Resolution
Not Specified by Manufacturer
Horizontal Resolution (TV Lines)
0 TV Lines
Gain
0 to 18 dB
Signal-to-Noise Ratio
63 dB
Camera
Lens Mount
Micro Four Thirds
Shutter Type
Mechanical Focal Plane Shutter and Electronic Rolling ShutterĀ
Precise Scan Rate Control
No
Built-In ND Filter
No
Built-In Microphone
Stereo
Broadcast System Compatibility
NTSC, PAL
Interfaces
CCU I/O
No
Video I/O
1x HDMI 2.0 Output
1x Micro BNC (12G-SDI) Input
1x Micro BNC (12G-SDI) Output
Audio I/O
1x 1/8" / 3.5 mm TRS Stereo Microphone Input
Other I/O
2x USB-C (USB 3.2 / 3.1 Gen 1) Control/Data/Video Input/Output
Recording
Recording Modes
DNxHD/ProRes:
3840 x 2160p at 23.98/24/25/29.97/30/50/59.94/60 fpsĀ
1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fpsĀ
Raw Recording
Blackmagic RAW
3840 x 2160 at 23.98/24.00/25/29.97/50/59.94/60 fps [26 to 190 Mb/s]
Audio Recording
Raw: 2-Channel 24-Bit 48 kHz LPCM Audio
Display
Display Type
No
Power
Power I/O
1x Barrel (12VDC) Input
Power Consumption
>25 W
General
Operating Conditions
32 to 104Ā°F / 0 to 40Ā°CĀ up to 90% Humidity
Storage Conditions
-4 to 113Ā°F / -20 to 45Ā°CĀ
Shoe Mount
No
Accessory Mounting Thread
4x 1/4"-20 on Camera Body
Tripod Mount
No
Dimensions (W x H x D)
3.3 x 2.6 x 2.74" / 8.4 x 6.6 x 6.96Ā cm (Without Protrusions)
Weight
10.58Ā oz / 0.3Ā kg
Packaging Info
Package Weight
1.48 lb
Box Dimensions (LxWxH)
7 x 5.2 x 4"

What's in the Box:

  • Blackmagic Design Micro Studio Camera 4K G2
  • 12 VAC Power Supply with International Socket Adapters
  • Turret Dust Cap
  • Limited 1-Year Manufacturer Warranty
