Blackmagic Design SDI to Audio Mini Converter

Product image 1
Product image 2
Product image 3
Product image 4

Blackmagic Design SDI to Audio Mini Converter

Blackmagic Design SDI to Audio Mini Converter

Key Features
  • Auto SD/HD Switching
  • 3GB/s Technology
  • With Power Supply

Ā

Overview

TheĀ Blackmagic Design CONVMCSAUDĀ includes everything you need to de-embed 4 channels of analog audio or 8 channels of AES/EBU digital audio from any SDI video connection. Now you can easily access the audio in any SDI video connection for output to audio equipment such as audio mixers, analog broadcast decks, audio monitors and more!

Key Specs

SDI Input
SDI: Switchable between SD, HD and 3 Gb/s SDI
SDI Redundant: Automatically switches over if main SDI input is lost
Analog Audio
4 channels of professional balanced analog audio with standard 1/4 inch jack connections
AES/EBU
8 channels of professional balanced digital with standard 1/4 inch jack connections
Format
625/25 PAL, 525/29.97 NTSC, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080i50, 1080i59.94, 1080i60, 720p50, 720p59.94 and 720p60
Sampling
4:2:2
Power Requirements
12VDC (includes power supply)
Packaging Info
Package Weight
1.065 lb
Box Dimensions (LxWxH)
5.75 x 5.55 x 2.6"

What's in the Box:

  • Blackmagic Design SDI to Audio Mini Converter
  • Universal AC Adapter
  • Limited 3-Year Manufacturer Warranty
$244.79
